GH1640 Industrial Lathe

Warco GH1640

Machinery weighing 500kg or more - delivery price varies according to size, weight and location; subject to quote.

Heavy duty industrial capacity machines, for the serious machinist.

The GH1640 are metalworking lathes, ideal for heavy duty industrial use.

Huge capacity and highest levels of quality throughout.

Features include

• Chrome molybdenum headstock gears, hardened and ground.
• Large diameter spindle is supported by taper roller bearings.
• 80mm spindle bore.
• Very quiet operation.
• Solid, extremely high quality bed casting - cast iron for added rigidity.
• Hardened and ground sideways.
• Saddle slideways are Turcite-B coated.
• One shot lubrication system to slides.
• Jogging button.
• Offset tailstock facility.
• Five position carriage stop.
• Telescopic leadscrew covers.
• Removable gap bed to allow a 660mm swing.
• Universal gearbox for inch, metric and module threads - lever selection means change gears not required.
• All thread cutting pitches selected through gear box, no need to change individual gears.
• Full DRO system supplied and fitted.

Standard equipment includes

• Digital readout system
• Chuck 3 jaw 250mm self centering with inside & outside jaws
• Chuck 4 jaw 300mm independent
• Face plate 300mm
• Quick change tool post (as shown here)
• Fixed steady
• Travelling steady
• Coolant system
• Dead centres x2
• Full length rear splash guard
• Foot operated spindle brake
• Thread dial indicator
• Mounting pads and levelling screws
• Headstock reducer sleeve 7MT-5MT
• Light LED low voltage
• Operation manual with spare parts lists
• Tool box and maintenance tools.

Each machine also comes with an individual accuracy test report.

Machine: 4004DRO	GH1640
Product Dimensions:
Weight	2485kg
Length x Width x Height	2310 x 1000 x 1280mm
Tray Length x Width	1640 x 600mm
Shipping Dimensions
Length x Width x Height (DRO version)	2440 x 1150 x 1500mm
Power/Motor
Motor size	5.5kw
Power Transfer (GH) gearbox or (VS) variable speed	GH
Spindle speeds (No: and achievable speeds)	12: 42 - 1800
Voltage (240v single) (440v 3 Phase)	440v 3 Phase
Fitment (Plug connection type)	Hardwired
Current	50Hz 30A
Main Specifications
Maximum swing	410 / 660mm over gap
Centre height	205mm
Distance between centre’s	1000mm
Longitudinal travel (Z)	850mm
Cross slide travel (X)	230mm
Top slide travel (fine Z)	100mm
Spindle taper	MT7
Tailstock Taper	MT4
Tailstock quill travel	130mm
Spindle Bore	80mm
Tool shank size recommended for C/L	25mm
Metric and imperial threads	0.5-20mm / 72 – 1 5/8 tpi
Chuck mount	D1-8
Spindle Bearings/Drive	Taper Roller
Other Specifications
Country of origin	China
Warranty	12 Months
Approximated assembly and setup time	45 mins
CE approved Certificate	Yes, available upon request
Additional products
Optional stand	N/A
Optional Digital Read Out Kit	N/A
X scale	250mm
Z Scale	900mm
Chuck mount sizes	D1-8
Base/tray fixing holes dimensions A-B-C-D	A= 545 B= 505 C= 1440 D= 165mm
